Type: Micro ATX Form Factor; 24.4cm x 21.5cm. Editors: AM4 Socket: Support for AMD Ryzen 2nd Generation / Ryzen with Radeon Vega Graphics / Athlon with Radeon Vega Graphics / Ryzen 1st Generation Processors. (Click here to see the compatible processors from the manufacturer's site). Chipset: AMD B350. Memories: 4 x DDR4 DIMM sockets supports up to 64 GB memory, Dual channel memory architecture, Supported frequencies DDR4 3200 (OC) / 2933 (OC) / 2667/2400/2133 MHz, supports ECC Un-buffered DIMM 1Rx8 / 2Rx8 memory modules ( operates in non-ECC mode), supports non-ECC Un-buffered DIMM 1Rx8 / 2Rx8 / 1Rx16 memory modules, supports Extreme Memory Profile (XMP) memory modules. Disk support: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3 x4 / x2 SSD support), 4 x SATA 6Gb / s connectors, Support for RAID 0, RAID 1 , and RAID 10. Expansion ports: 1 x PCI Express x16 slot, running at x16 (PCIEX16), 1 x PCI Express x16 slot, running at x4 (PCIEX4), 1 x PCI Express x1 slot. Internal connections: 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 1 x system fan header, 1 x M.2 Socket 3 connector, 4 x SATA 6Gb / s connectors, 1 x front panel header, 1 x front panel audio header, 1 x S / PDIF Out header, 1 x CPU cooler LED strip / RGB LED strip header, 1 x USB 3.1 Gen 1 header, 2 x USB 2 / 1.1 headers , 1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2 module only), 1 x serial port header, 1 x Clear CMOS jumper. External connections: 1 x PS / 2 keyboard / mouse port, 1 x DVI-D port, 1 x HDMI port, 4 x USB 3.1 Gen 1 ports, 4 x USB 2 / 1.1 ports, 1 x RJ-45 port, 3 x audio jacks. Graphics: By inserting a PCI-Express graphics card or by a processor with built-in graphics. The processor uses the built-in ports of the motherboard and supports the following resolutions: DVI-D with a maximum resolution of up to 1920x1200 @ 60 Hz, HDMI with a maximum resolution of up to 4096x2160 @ 60 Hz. Built-in sound card: Realtek ALC887 codec. Built-in network card: Realtek GbE LAN chip (10/100/1000 Mbit). Compatible operating system: Microsoft Windows 7, 10 64-bit.
