AM3 + socket processor Support for AMD AM3 + processors Support for AMD AM3 Phenom ™ II / AMD Athlon ™ II processors Please refer to the "List of Supported Processors" for more information. Hyper Transport Bus Support up to 5200MT / s HyperTransport ™ 3 Chipset North Bridge AMD 760G South Bridge AMD SB710 Memory 2 x 1.5V DDR3 DIMM sockets to support up to 16GB of system memory. * Due to the limitation of the Windows 32-bit operating system, when we install more than 4 GB of physical memory, the actual size to be used will be less than the installed one. Memory support with Dual Channel architecture DDR3 1333+ (O.C.) / 1066/800 MHz memory support (Please see "List of supported memories" for more information.) Graphics Circuit * DVI-D port does not support D-Sub connection via adapter. Built-in North Bridge 1 x D-Sub port 1 x DVI-D port, with maximum resolution support 1920x1200 Sound 2/4 / 5.1 / 7.1-channels (To adjust the 7.1-channel audio, you need to connect the port to HD Audio standard via the front panel and activate the multi-channel mode via the driver) High Definition Audio Realtek ALC887 HD audio codec LAN 1 x Atheros GbE LAN chip (10/100/1000 Mbit) Expansion sockets 1 x PCI Express x16 slot, with x16 function 1 x PCI Express x1 1 x PCI (All PCI Express jacks are compatible with the PCI Express 2 standard) South Bridge storage interface 6 x SATA 3Gb / s sockets to support up to 6 SATA 3Gb / s devices Support for SATA RAID 0, RAID 1, RAID 10 and JBOD USB South Bridge Up to 8 USB 2 / 1.1 ports (4 on the back, 4 via the USB bracket connected to the internal USB contact) Internal sockets 6 x SATA 3Gb / s 1 x CMOS cleaning short circuit 1 x CPU fan contact 1 x front panel contact 1 x front audio jack 1 x contact for system fan 1 x serial port contact 2 x USB 2 / 1.1 1 x 24-pin ATX power adapter 1 x 4-pin ATX 12V power adapter Rear slots 1 x D-Sub 1 x DVI-D 1 x PS / 2 mouse slot 1 x PS / 2 keyboard slot 1 x RJ45 LAN 3 x Audio jacks (Line-in / Line-out / MIC) 4 x USB 2 / 1.1 I / O Controller iTE IT8728 Control circuit CPU / System fan controller Where the CPU fan speed control function is supported depends on the fan installed. CPU / system fan speed detector CPU / system fan failure warning CPU / system temperature detection Ability to detect system voltage (Voltage) CPU overheating warning BIOS DualBIOS τεχνο technology support PnP 1a, DMI 2, SM BIOS 2.4, ACPI 1b 2 x 16 Mbit flash Licensed AWARD AND BIOS other characteristics Q-Share support Smart Recovery Cloud OC support Q-Flash ™ Download Center Xpress ™ Install Xpress ™ Recovery 2 Xpress AND BIOS Rescue Support for APP Center Auto Green EasyTune support * Available EasyTune features may differ by motherboard model @ BIOS ™ On / Off Charge support Support for 3TB + Unlock Bundled Software Norton Internet Security (OEM version) Operating system Support for Microsoft ® Windows 7 / Vista / XP Motherboard type Micro ATX Form Factor, 244mm x 206mm
