Ethernet Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX Interface 1 * RJ11 ADSL Port, 1 * 10/100Mbps Auto MDI/MDIX RJ45 LAN Port (Optional Ethernet WAN for LAN Port) LED PWR, WLAN, WPS, ADSL, Internet, LAN Power Supply DC 12V/500mA(Output) Button WPS, Default, Power ON/OFF Dimensions (L x W x H ) 144.5 * 90 * 26.5 mm Software ADSL Version ADSL, ADSL2, ADSL2+ Data Rate Downstream: Up to 24Mbps Upstream: Up to 1Mbps ATM / PPP Protocol ATM Forum UNI3.1/4 PVC (up to 8PVCs) ATM Adaptation Layer Type 5 (AAL5) ATM QoS Bridged and Routed Ethernet Encapsulation VC and LLC Based Multiplexing PPP over Ethernet (RFC2516) PPP over ATM (RFC 2364) IPoA (RFC1577/2225) Main Feature DHCP, DHCP Relay NAT, Static Routing VPN (PPTP, L2TP, IPsec) Pass-through PVC/Ethernet Port Mapping DNS Relay, DDNS IGMP Multicast, IGMP Snooping V1/V2 Virtual Server, DMZ, ACL (Access Control List) UPnP IPv6 Management Web Based Configuration (HTTP), Remote Management, Telnet Management, Command Line Interface, TR-069, SNMP, Web Based Firmware Upgrade, CWMP (TR-069), Diagnostic Tools Wireless Standards IEEE802.11g, 802.11b,802.11n Frequency Range 2.4-2.4835GHz Wireless Speed Up to 150Mbps Wireless Security WEP 64/128bits, WPA(TKIP/AES)/WPA2(TKIP/AES)/WPA2 Mixed, 802.1x Authentication Wireless MAC Filtering Wireless Security Power 20dBm Antenna Type 1* 5dBi Fixed Antenna Others Certification CE, FCC Environment Operating Temperature: 0℃~40℃ Storage Temperature: -40℃~70℃ Operating Humidity: 10%~90%RH non-condensing Storage Humidity: 5%~90%RH non-condensing Package 1 * DL4310 1 * 12V/500mA Power Adapter 2 * RJ11 Telephone Cable 1 * RJ45 Ethernet Cable 1 * ADSL Splitter 1 * Quick Installation Guide (Multilingual)
